SecurityCore Family (Application specific MCU for Security system)
Product Features Volt
[V]		 I2C Package
SecurityCore4.1 Application Specific MCU for Security System 2.7 ~ 5.5 100kHz 8-SOP
SecurityCore5.0 Application Specific MCU for Security System 2.2 ~ 5.5 100kHz 8-SOP
ChargerCore Family (Application specific MCU for control)
Product FLASH
[Byte]		 EEPROM
[Byte]		 RAM
[Byte]		 Volt
[V]		 Freq.
[MHz]		 T/C WDT ADC
(bit x ch)		 PWM
(bit x ch)		 Contr. Package
ChargerCore300 2k (128) 128 2.4 ~ 5.5 12
(24)		 2 1 10X8 8X1 OVP
CC-CV		 20-TSSOP
CICore Family (Common Interface Controller for STB Application)
Product Features Type Others Package
CICore1.0 Common Interface Controller for STB system Processing One MPEG stream I2CCI standard 128-PQFP
CICore2.0 Common Interface Controller for STB system Processing Two MPEG streams I2CCI standard 160-LQFP
ResetCore Family (Voltage Detector - Reset IC)
Product Operating
Voltage[V]		 Supply
Current		 RESETB Signal Generation
Starting Voltage [V]		 RESETB Output
Voltage, High		 RESETB Output
Voltage, Low		 Package
Min. Typ. Max.
ResetCore250 1.6 ~ 5.5 Max. 30uA 2.4 2.5 2.6 Min. 0.7VDD Max. 0.3VDD SOT-23
ResetCore270 1.6 ~ 5.5 Max. 30uA 2.6 2.7 2.8 Min. 0.7VDD Max. 0.3VDD SOT-23
ResetCore290 1.6 ~ 5.5 Max. 30uA 2.8 2.9 3 Min. 0.7VDD Max. 0.3VDD SOT-23
Others ResetCore170 / 190 / 210 / 230 / 310 / 330 / 350 / 370 / 390 / 410 / 430 / 450
RingCore Family (Application specific MCU for Vibration control)
Product Actuator
Support		 Output
Resonant
Frequency		 PWM Input
Frequency		 Wake-up
Time		 Output
Offset		 ActiveCurrent
(PWM Duty
50%)		 Stand-by
Current		 Auto
Tuning		 Package
RingCore200 LRA, ERM 80Hz < 390Hz 10kHz < 50kHz 1ms after EN Typ. 50mV ~5mA ~1uA - 8-DFN
RingCore220 LRA, ERM 80Hz < 390Hz 10kHz < 50kHz 1ms after EN Typ. 50mV ~5mA ~1uA Support 10-DFN
